OBDSTAR | SKU: M073

OBDSTAR (M073) | Indmar 6-pin OBD – 16-pin OBD2 Adapter Cable | Motor Boat

Name: OBDSTAR (M073) | Indmar 6-pin OBD – 16-pin OBD2 Adapter Cable | Motor Boat
Brand: OBDSTAR
SKU: M073
Price: 26.95 EUR
Availability: InStock

€26,95 incl.

€22,27 excl.

Warranty directly via AsTools

We handle warranty cases ourselves, quickly and without involving the manufacturer. Thanks to our own parts inventory and technical expertise, we can usually assist you immediately. Only in exceptional cases do we still send the product to the supplier.

2 years warranty on all products

All our products come with a 2-year factory warranty. This ensures you long-lasting quality and service.

Easy returns

You can easily request your return through your account. We will send you the return label by email. Return shipping costs are your responsibility.

Professional customer service

Our experts are ready to help you quickly and professionally, both online and in our physical store. Questions? Feel free to contact us!

The OBDSTAR M073 connects the 6-pin diagnostic connector of Indmar inboard engines to the 16-pin OBD2 side of your OBDSTAR marine device. The connector is located in the engine compartment of the boat.

A boat engine does not have an OBD2 port like a car. With this cable you can reach the engine control and read out fault codes and live data. OBDSTAR supplies the M073 with the inboard version of the D800 and the MarineMaster; the device itself must provide the Indmar diagnostics.

HIGHLIGHTS

✔Makes the 6-pin Indmar connector accessible for an OBDSTAR device with a 16-pin input.

✔Original OBDSTAR adapter, the same as in the inboard packages of the D800 and the MarineMaster.

✔You read out the engine with your own device, without a separate Indmar test device.

✔Useful as a replacement for a lost or damaged M073 from your device package.

POINTS TO NOTE

✕Your reader must support the Indmar diagnostics of this engine; the cable does not convert protocols.

✕A simple EOBD code reader does not work with this cable; it only reads emissions data from cars.

✕OBDSTAR does not provide a list of engine types and build years; the connection to the engine is decisive.

✕Only for the 6-pin Indmar connector; engines with a different plug require a different cable.

Applications and functions

The cable is intended for boat mechanics and workshops that read out Indmar inboard engines with the 6-pin connector.

Control units you can access

Engine control: ECU of the inboard engine.
Other systems: Varies by engine and tool.

What you can do

Fault codes: Read and clear.
Live data: Engine speed, temperatures and sensors.
Fault finding: Where the diagnostic tool offers it.

How to use it

Engine off: Switch off the engine and open the engine compartment.
Locate the connector: Find the 6-pin diagnostic connector.
Connect: Insert the plug straight and fully.
Connect the diagnostic tool: Connect the 16-pin end and switch the ignition on.
Read: Select the brand, the engine and the function.

Compatible vehicles and applications

The deciding factor is the 6-pin Indmar diagnostic connector. If your engine has that connector, the cable fits.

Indmar:

Inboard engines: With the 6-pin diagnostic connector.

💡

Good to know: Count the contacts of the diagnostic plug in the engine compartment. If there are six contacts, this cable fits.

Package contents

1x OBDSTAR (M073) | Indmar 6-pin OBD - 16-pin OBD2 Adapter Cable | Motor Boat

Technical specifications

General

The brand of the cable or adapter. It often has to match the brand of your diagnostic tool.Brand: OBDSTAR
The type of product: a separate adapter cable, an adapter without a cable or a complete set.Product type: Adapter cable

Suitable for

The brand of diagnostic tool the cable works with. A cable for one brand usually does not fit a tester of another brand.Compatible diagnostic tool: OBDSTAR
Whether the cable needs a separate power connection, for example via battery clamps. A passive cable works without one.Separate power supply required: No

Connections

The connector that plugs into the diagnostic port of the vehicle or machine. It must fit exactly.Vehicle-side connector: 6-pin OBD
The connector on the side of your diagnostic tool or interface. Usually a 16-pin OBD2 connector.Tool-side connector: 16-pin OBD2 (J1962)
