The OBDSTAR M037 converts the Ducati 4-pin diagnostic connector to a standard 16-pin OBD2 (J1962) interface. The 4-pin side connects to the motorcycle's factory connector, whilst the OBD2 side plugs directly into your OBDSTAR diagnostic device.
Ducati fitted a proprietary 4-pin connector on a wide range of models instead of the universal OBD2 port. The cable translates that pin configuration to the corresponding OBD2 pins, allowing the device to communicate with the engine control unit (ECU) via the vehicle's native communication protocol. The specific protocol varies by model; the cable itself performs no active signal processing. What you gain is diagnostic access to the ECU. Further operations such as programming or coding depend on your device's software and licence, not the cable.
KEY BENEFITS
IMPORTANT NOTES
Applications and functionality
Via the 4-pin connection, you can access the Ducati engine control unit.
Control units you can reach
- Engine control unit (ECU): The engine management control module, connected to the 4-pin diagnostic connector.
- Other units: Availability of additional units varies by model and device.
What you can do
- Read fault codes (DTCs): Retrieve stored and active fault codes from the engine management system.
- Clear fault codes: Remove codes from the ECU memory after diagnosis or repair.
- Stream live data: Monitor sensor readings and operating parameters in real time via the diagnostic connection.
- ECU programming and coding: Adjust ECU parameters or programme control units, depending on your OBDSTAR device's software licence.
- Note: Which of these functions are available depends on the model and licence of your OBDSTAR device.
Compatible vehicles and applications
The 4-pin diagnostic connector is the determining factor, not the model itself. The Ducati models listed below are equipped with this connector; only confirmed models are shown.
Ducati:
- Monster 600: (1993–2001)
- Monster 620: (2002–2006)
- Monster 695: (2006–2008)
- Monster 750: (1996–2002)
- Monster 800: (2003–2004)
- Monster 900: (1993–2002)
- Monster 1000: (2003–2005)
- Monster S2R: (2004–2008)
- Monster S4: (2001–2003)
- Monster S4R: (2003–2008)
- Multistrada 620: (2005–2006)
- Multistrada 1000: (2003–2006)
- Multistrada 1100: (2007–2009)
- Supersport 900: (1998–2002)
- 748: (1994–2002)
- 916: (1994–1998)
- 996: (1999–2001)
- 998: (2002–2004)
- 999: (2003–2006)
- 1098: (2007–2009)
- 1198: (2009–2011)
Package contents
- 1x OBDSTAR (M037) | Ducati 4-pin OBD to 16-pin OBD2 Adapter Cable | Motorcycle
Technical Specifications
| Specification | Description |
|---|---|
| Brand | OBDSTAR |
| Part Number | M037 |
| Type | Adapter Cable |
| Application | Ducati motorcycles with 4-pin diagnostic connector |
| Vehicle-side Connection | Ducati 4-pin OBD |
| Device-side Connection | 16-pin OBD2 (J1962) |
| Control Units | Motorcycle engine control unit (ECU) |
| Segment | Motorcycle |
| Supported Brands | Ducati |
| Model Range | Ducati models manufactured from 1993 to 2011, provided they are equipped with the 4-pin connector |
| Required to Use | OBDSTAR diagnostic device with motorcycle coverage, such as the MS50, MS70 or MotoMaster |
| Additional Requirements | None; the cable operates without adapter or separate power supply |
| Weight | 0.1 kg |
