Cojali  |  SKU: 2260110

Cojali (2260110) | 15-pin – 7-pin Type-S Spiral Adapter | Trailer

€34,95 incl.
€19,95 incl.
€16,49 excl.

Warranty directly via AsTools

We handle warranty cases ourselves, quickly and without involving the manufacturer. Thanks to our own parts inventory and technical expertise, we can usually assist you immediately. Only in exceptional cases do we still send the product to the supplier.

2 years warranty on all products

All our products come with a 2-year factory warranty. This ensures you long-lasting quality and service.

Easy returns

You can easily request your return through your account. We will send you the return label by email. Return shipping costs are your responsibility.

Professional customer service

Our experts are ready to help you quickly and professionally, both online and in our physical store. Questions? Feel free to contact us!

The Cojali 2260110 is a spiral adapter with a 15-pin connector (ISO 12098) on one end and two 7-pin plugs (male) on the other: a Type S (ISO 3731, white) and a Type N (ISO 1185, black). Cojali intends it for the tractor side with 7S/7N connections.

In the Cojali catalogue, the adapter is listed as an optional cable for the Jaltest PTE, the testing device for power and signals between tractor and trailer. For the British market, it is required according to that catalogue.

BENEFITS

✔Allows a tractor with 7-pin Type N and Type S to be connected to a 15-pin connection, such as that of the Jaltest PTE.
✔The black 24N and the white 24S plugs can be told apart by colour, so you can connect them correctly in one step.
✔In addition to lighting and power, the adapter also connects pins 10, 11 and 12 of the 15-pin plug.
✔The operating temperature of -40 to 80 °C makes the adapter suitable for outdoor use.

POINTS OF ATTENTION

✕The adapter does not have ISO 7638; for the EBS/ABS connection, the 2260113 is the correct cable.
✕Pins 13, 14 and 15 of the 15-pin plug are not connected through.
✕Cojali does not state a length; it is an adapter, not a complete spiral cable between tractor and trailer.
✕Only for 24V systems; the adapter is not intended for 12V trailers.

Applications and functionality

The adapter connects the 7-pin 24N and 24S connections of a tractor to a 15-pin connection, for example when testing with the Jaltest PTE.

What the cable connects

  • 15-pin to 24N: Pins 1, 2, 4, 5, 6, 7 and 10.
  • 15-pin to 24S: Pins 3, 4, 8, 9, 11 and 12.
  • Pin 9 to 24S: On pin 2 and pin 4.
  • Earth: Pin 4 to pin 1 of both plugs.
  • Not connected: Pins 13, 14 and 15.

What you can do

  • Testing the tractor: Check the 24N and 24S with the Jaltest PTE.
  • Converting: 7S/7N from the tractor to 15-pin.
  • Reading: Per function on the PTE's LEDs.

How to use it

  1. Check the plugs: Make sure the pins are clean and straight.
  2. Connecting Type N: Insert the black plug into the 24N of the tractor.
  3. Connecting Type S: Insert the white plug into the 24S of the tractor.
  4. Connecting the 15-pin: Connect the 15-pin side to the PTE cable.
  5. Checking functions: Switch on the functions and read the LEDs.

Compatible vehicles and applications

The deciding factor is the tractor with 7-pin Type N and Type S. The adapter converts those connections to ISO 12098.

ISO 1185 and ISO 3731 to ISO 12098:

  • Tractors with 24N and 24S connection: According to ISO 1185 and ISO 3731.
💡
Good to know: The Type N plug is black, the Type S plug is white. If the tractor only has a 15-pin socket, you do not need this adapter.

Package contents

  • 1x Cojali (2260110) | 15-pin - 7-pin Type-S Spiral Adapter | Trailer

Technical specifications

General

The brand of the cable or adapter. It often has to match the brand of your diagnostic tool.Brand
Cojali
The type of product: a separate adapter cable, an adapter without a cable or a complete set.Product type
Adapter

Suitable for

The brand of diagnostic tool the cable works with. A cable for one brand usually does not fit a tester of another brand.Compatible diagnostic tool
  • Jaltest
The Jaltest module required to use the cable. Without the correct licence, the cable will not work.Jaltest software module
  • PTE trailers

Connections

The temperature range within which the cable can be used safely.Operating temperature
-40 to 80 °C

Size and weight

Reference number
2,260,110

Other specifications

Application
Tractor 7S/7N to 15-pin, including for Jaltest PTE
Tractor side connection
7-pin Type S (ISO 3731, white) and 7-pin Type N (ISO 1185, black), male
Trailer side connection
15-pin ISO 12098
Standard
ISO 12098, ISO 1185, ISO 3731
