Jaltest  |  SKU: JDC518A

Jaltest (JDC518A) | SISU 3+9-pin OBD – 16-pin OBD2 Adapter Cable | Internal combustion engine

Regular price
€161,95 incl.
€133,84 excl.

Warranty directly via AsTools

We handle warranty cases ourselves, quickly and without involving the manufacturer. Thanks to our own parts inventory and technical expertise, we can usually assist you immediately. Only in exceptional cases do we still send the product to the supplier.

2 years warranty on all products

All our products come with a 2-year factory warranty. This ensures you long-lasting quality and service.

Easy returns

You can easily request your return through your account. We will send you the return label by email. Return shipping costs are your responsibility.

Professional customer service

Our experts are ready to help you quickly and professionally, both online and in our physical store. Questions? Feel free to contact us!

The Jaltest JDC518A connects SISU engine diagnostics to your Jaltest equipment and ends on the machine side in two connectors side by side. The first branch is a 3-pin CAN backbone connector with a grey locking bracket and a green contact carrier, for the continuous CAN line of the engine. The second branch is a 9-pin SUB-D with a metal shell and two screws, for the separate 9-pin diagnostic connection. On the interface side is the 16-pin OBD2; the cable measures 28 to 30 cm.

With this connection, the Jaltest software reads the four SISU engine control units in the coverage: EEM2 with the VP30/VP44 distributor pump, EEM3 based on EDC 7 UC31, EEM4 based on EDC 17 CV54 and EEM4S5 based on EDC MD1. For all four, fault codes, measured values and the maintenance intervals are included in the coverage; the additional actions are added for the two newest. The coverage extends to Jaltest AGV, OHW, MHE and Marine.

ADVANTAGES

✔Supports all four SISU engine control units in the coverage: EEM2, EEM3, EEM4 and EEM4S5.
✔For each of those four control units, fault codes, measured values and the maintenance intervals are included in the coverage.
✔On the newer EEM4 and EEM4S5, the additional actions are added, such as reset and adjustment procedures.
✔Covers both the older VP30/VP44 distributor pump and the later engines with common rail injection.

POINTS TO NOTE

✕Additional actions are only included in the coverage for EEM4 and EEM4S5; on EEM2 and EEM3 it remains limited to reading out.
✕For SISU engines, Jaltest offers no component control, not even on the newest control unit.
✕The machine side is fixed to these two connectors; if your engine has a different diagnostic connection, this cable will not fit.
✕This version belongs to the Jaltest Link V8.1 and not to the V9.

Applications and functionality

The cable is intended for workshops that read out SISU engines in tractors, machines and stationary installations. Which of the four control units is fitted depends on the engine generation and the injection system.

Control units you can access

  • EEM2 (VP30/VP44): Electronic distributor pump.
  • EEM3 (EDC 7 UC31): First common rail generation.
  • EEM4 (EDC 17 CV54): With additional actions.
  • EEM4S5 (EDC MD1): Current version.

What you can do

  • Fault codes: Read and clear, with description.
  • Measured values: View live, with alarm limits.
  • Maintenance: Retrieve and record intervals.
  • Additional actions: Only on EEM4 and EEM4S5.

How to use it

  1. Check connector: See whether a CAN backbone or SUB-D is fitted.
  2. Connecting: Use the branch that fits your engine.
  3. Link pairing: Connect the OBD2 end to the Jaltest Link V8.1.
  4. Ignition on: Switch the ignition on, without starting the engine.
  5. Reading out: Select SISU and the engine generation.

Compatible vehicles and applications

The engine determines it, not the machine it sits in. SISU supplies the unit as a separate drive, so the engine generation determines what you find, not the brand of tractor or machine. Check on the unit itself whether the 3-pin CAN backbone or the 9-pin SUB-D is fitted. The applications below come from the SISU coverage.

SISU:

  • SISU engines: The EEM2, EEM3, EEM4 and EEM4S5 generations.
  • Agricultural tractors: With a SISU unit as drive, including Massey Ferguson.
  • Construction and off-road machines: And lifting & hoisting equipment with a SISU unit.
  • Stationary installations: Such as generator sets.
💡
Good to know: The machine side consists of two separate connectors that both belong to the engine: a 3-pin CAN backbone and a 9-pin SUB-D. You recognise them by the green contact carrier and the metal shell with screws respectively. Check on the machine itself which of the two is fitted before ordering.

Package contents

  • 1x Jaltest (JDC518A) | SISU 3+9-pin OBD - 16-pin OBD2 Adapter Cable | Internal combustion engine

Technical specifications

General

The manufacturer of the cable. Jaltest cables work with Jaltest diagnostic equipment.Brand
Jaltest (Cojali)
The type of cable. A diagnostic cable connects to the diagnostic socket, a measuring cable tests an individual component.Cable type
Adapter cable
The Jaltest software package the cable belongs to. A licence for that module is required to use the cable.Jaltest software module
  • AGV agriculture
  • OHW construction and off-road
  • MHE internal transport
  • Marine vessels

Connections

The version of the Jaltest Link diagnostic interface the cable fits. Not every cable works with every version.Compatible Jaltest Link
  • Jaltest Link V8.1
The connector on the diagnostic device side. It must fit your interface or diagnostic cable.Interface-side connector
16-pin OBD2
The connector on the vehicle, engine or machine side. It must fit the diagnostic socket or the component.Vehicle-side connector
3+9-pin OBD
The length of the cable. A longer cable allows more room to work.Cable length
28 to 30 cm

Diagnostics

Whether fault codes can be cleared as well as read. Some systems only allow reading.Clear fault codes
Yes
Whether the current sensor values can be viewed while the vehicle is running. Useful for tracing a fault.View live data
Yes
Whether you can see when the next service is due. Useful for planning a service appointment properly.View service data
Yes

Usage

Reference number
JDC518A
Control units
EEM2, EEM3, EEM4 and EEM4S5 (engine control)
Required for use
Jaltest Link V8.1

Other specifications

Application
SISU engines with a 3-pin CAN backbone or 9-pin SUB-D connection
