VT01704C | Citroën/Peugeot/BMW/MINI - 1.4/1.6 | Timing set (13-piece)

The timing set (VT01704C) is a tool kit for checking and adjusting engine timing on 1.4 and 1.6 liter petrol engines used in various models of BMW, MINI, Citroën, and Peugeot. This set is used for tasks such as replacing the timing chain, the cylinder head gasket, or other engine repairs requiring disassembly of the timing system.

The set contains specific tools for locking the camshafts and the crankshaft in their Top Dead Center (TDC) position, ensuring correct timing. Additionally, a chain tensioner tool is included to maintain the proper tension on the timing chain during installation. The components are supplied in a plastic storage case for storage and transport.

Application and functionality:

This set is designed for performing maintenance and repairs on the timing system of the specified engines.

• Locking the camshafts: The supplied locking plates secure the intake and exhaust camshafts to ensure valve timing during maintenance work.
• Locking the crankshaft: A locking pin is used to fix the crankshaft in the TDC position via the flywheel.
• Tensioning the timing chain: The chain tensioner tool simulates the working pressure of the hydraulic chain tensioner, enabling correct installation of the chain.

Compatible vehicles and engine codes:

Suitable for various models of BMW, MINI, Citroën, and Peugeot equipped with the N12, N14, and EP series petrol engines.

BMW:

• 1-series (E81/E82/E87/E88): (2006–2014)
• 3-series (E90/E91/E92/E93): (2006–2014)

Citroën:

• C3 (II): (2009–2016)
• C3 Picasso: (2009–2017)
• C4 (I/II): (2008–2018)
• C4 Picasso: (2008–2013)
• C5 (III): (2009–2015)
• DS3: (2009–2015)

MINI:

• Clubman (R55): (2007–2014)
• Cooper (R56): (2006–2013)
• Countryman (R60): (2010–2016)
• Coupé (R58): (2011–2015)
• One (R56): (2007–2010)
• Paceman (R61): (2013–2016)
• Roadster (R59): (2012–2015)

Peugeot:

• 207: (2006–2013)
• 208: (2012–2015)
• 3008: (2009–2015)
• 308: (2007–2015)
• 5008: (2009–2015)
• 508: (2011–2015)
• RCZ: (2010–2015)

Engine codes:

• 1.4L: 8FR (EP3), 8FS (EP3), EP3, EP3C, N12, N12B14
• 1.6L: 5FR (EP6), 5FS (EP6C), 5FT (EP6DT), 5FV (EP6CDT), 5FW (EP6), 5FX (EP6DT), EP6, EP6C, EP6CDT, EP6DTS, N14, N14B16A

Package Contents:

• 1x Camshaft locking tool (intake) – OEM: 119540, 0197-A1, 0197-A3
• 1x Camshaft locking tool (exhaust) – OEM: 117440
• 1x Crankshaft locking pin – OEM: 119590, 0197-BZ
• 1x Chain tensioner tool – OEM: 119340, 0197-M
• 4x Mounting screw
• 1x Storage case
