Jaltest  |  SKU: JDC624A

Jaltest (JDC624A) | Tohatsu (Kokusan Denki) 18-pins ECU – 16-pins OBD2 Adapter Cable | Motorboat

€222,95 incl.
€184,26 excl.

Warranty directly via AsTools

We handle warranty cases ourselves, quickly and without involving the manufacturer. Thanks to our own parts inventory and technical expertise, we can usually assist you immediately. Only in exceptional cases do we still send the product to the supplier.

2 years warranty on all products

All our products come with a 2-year factory warranty. This ensures you long-lasting quality and service.

Easy returns

You can easily request your return through your account. We will send you the return label by email. Return shipping costs are your responsibility.

Professional customer service

Our experts are ready to help you quickly and professionally, both online and in our physical store. Questions? Feel free to contact us!

The Jaltest JDC624A is the adapter cable that connects the 18-pin ECU connector of Tohatsu outboard motors to a standard 16-pin OBD2 interface. The cable connects directly to the engine control unit connector located under the engine cover, rather than to a diagnostic port in the wiring harness. Tohatsu also uses two 6-pin configurations, each designed for a specific power class (10-20 hp and 40-60 hp).

Behind this single connector lie both engine control systems that Jaltest supports for Tohatsu: The ECM (Engine Electronic Control) from the MFS series and the ECM PGM-FI (Programmed Fuel Injection) from the BFT series. The coverage difference between them is this: With the ECM PGM-FI you can also adjust parameters and perform calibrations, but not with the ECM on the MFS models. Since outboard motors have no standardized connector requirement, this proprietary connector remains in use on newer engines as well. The cable falls under Jaltest Marine.

KEY BENEFITS

✔Connects directly to the 18-pin ECU connector without needing to locate a diagnostic port in the wiring harness.
✔Reaches both engine control systems through this single connector: ECM on the MFS series and ECM PGM-FI on the BFT series.
✔Full feature set available on the BFT series: Fault codes, component control, parameters, calibration and maintenance reset.
✔No model year restrictions: Outboard motors have no mandatory standard connector, so the proprietary connector remains in use on newer engines.

IMPORTANT NOTES

✕Feature set varies by engine series: The MFS models lack parameters and calibration functions, while the BFT series includes them.
✕The maintenance reset is not available on all models — it's supported on the MFS 115 and BFT series, but not on the smallest MFS models.
✕Only for the 18-pin ECU connector; for the 6-pin connector you'll need the JDC632 version (10-20 hp) or the JDC633A (40-60 hp).
✕Requires a Jaltest Link with valid Marine license; the cable itself does not provide coverage.

Applications and features

Using this connection, you can access the engine control unit of your Tohatsu outboard motor with Jaltest software. Available functions vary depending on the engine series.

Control units you can access

  • ECM — Engine Electronic Control: The engine management system of the MFS series, including fault codes, live data, component activation, ECU information and maintenance reset.
  • ECM PGM-FI — Programmed Fuel Injection: The engine management system of the BFT series, plus parameters and calibration options.

What you can do

  • Read fault codes: Access the fault memory of the engine control unit with detailed descriptions of detected issues.
  • View live data: Monitor real-time sensor readings connected to the engine control unit.
  • Activate components: Run active tests on the engine management system.
  • Parameters and calibration: Available on the ECM PGM-FI of the BFT series only, not on MFS models.
  • Reset maintenance: Reset the service interval counter, including on the MFS 115 and BFT series.

Compatible vehicles and applications

The connector type determines compatibility, not the model. This cable works with any Tohatsu outboard motor featuring the 18-pin ECU connector. Jaltest Marine covers the series listed below; check your motor's connector type on site to confirm.

Tohatsu:

  • MFS series: MFS 9.9, 15, 20, 25B/25C/25D, 30B/30C/30D, 40, 50, 60, 75, 90, 100, 115 and 140
  • BFT series: BFT60, BFT75, BFT80, BFT90, BFT100, BFT115, BFT150, BFT200, BFT225 and BFT250
  • BFW series: BFW60
  • MD series: MD25 JET, MD35 JET, MD40, MD50, MD70, MD75, MD90 and MD115
💡
Good to know: This cable connects directly to the 18-pin connector on the engine control unit, which is located under the engine cover. Tohatsu models with a 6-pin diagnostic connector require a different cable. Be sure to check which connector your outboard motor has before placing your order.

Package contents

  • 1x Jaltest (JDC624A) | Tohatsu (Kokusan Denki) 18-pin ECU – 16-pin OBD2 Adapter Cable | Motorboat

Technical specifications

Specification Description
Brand Jaltest (Cojali)
Reference number JDC624A
Type Adapter cable
Application Tohatsu outboard motors with 18-pin ECU connector
Engine-side connector 18-pin ECU
Interface-side connector 16-pin OBD2
Control units ECM (Engine Electronic Control) and ECM PGM-FI (Programmed Fuel Injection)
Segment Motorboat (marine)
Jaltest module Jaltest Marine
Part of cable set Not included in a cable set; sold separately in the Jaltest catalog
Required to use Jaltest Link with valid software license
