Topdon TCView TC004 | Thermal Imaging Camera

The Topdon TCView TC004 is a handheld thermal imaging camera designed for professional inspections and diagnostics. This standalone device operates without the need for a smartphone and is equipped with a thermal sensor with a resolution of 256x192 pixels. The camera can measure temperatures within a range of -20°C to +350°C. The lens has a fixed focal length of 3.2 mm and the thermal sensitivity is less than 40 mK, enabling the detection of small temperature differences.

Images are displayed directly on the built-in 2.8-inch LCD screen and stored on the included 32GB SD card. For detailed analysis and reporting, the stored data can be transferred to a computer via a USB connection and processed with the accompanying PC software. The TC004 features functions such as an adjustable temperature alarm, a built-in LED work light for use in dark environments, and multiple color palettes to customize the display of thermal images.

Application and functionality:

The TC004 is developed for visualizing temperature differences, making it a suitable instrument for various diagnostic and inspection applications. The handheld design ensures the device operates completely independently.

• Handheld design: The camera is an all-in-one device with an integrated display, making it independent of external devices such as a smartphone or tablet.
• Temperature alarm: Users can set upper and lower temperature limits. The camera gives a visual alarm when the measured temperature falls outside this range.
• LED work light: A built-in LED lamp provides extra illumination during inspections in poorly lit spaces.
• Multiple color palettes: The camera offers various color palettes, including White Hot, Black Hot, and Rainbow, to present thermal data in the clearest way for the specific application.

Measurement capabilities and applications:

Thanks to the specifications, the TC004 is suitable for a wide range of professional applications where temperature measurement is important.

• Automotive inspection: Suitable for diagnosing problems in engines, exhaust systems, bearings, and HVAC systems by identifying overheating or irregular heat patterns.
• Building inspection: Deployable for detecting heat leaks in insulation, moisture issues behind walls, and checking the performance of heating and cooling systems.
• Electrical inspection: Helps identify overheated components in electrical panels, fuse boxes, and wiring to prevent potential failures or fire hazards.
• Industrial maintenance: Usable for inspecting mechanical and electrical installations to plan preventive maintenance and minimize downtime.

Storage and connectivity:

The camera is designed for easy storage and transfer of thermal images for analysis and reporting.

• Storage: Images and data are stored on a removable 32GB SD card, which is included as standard.
• Connectivity: A USB port allows the camera to be charged and the collected data to be transferred to a computer for further processing.

Compatible software and platforms:

The collected thermal data can be further analyzed using software designed for processing thermal images.

• PC analysis software: With the accompanying software for the computer, users can analyze stored images, perform measurements, and generate professional reports.

Package Contents:

• 1x Topdon TCView TC004 thermal imaging camera
• 1x 32GB SD card
• 1x USB cable
• 1x Charger
• 1x Carrying bag
• 1x Manual

Technical specifications:
